产品样本
型号描述
适合气动系统的二位三通和二位五通压电阀
Type Description
The 6520 EExi valves are used for process actuation in hazardous areas. Thanks to the intrinsically safe design and the choice of corrosion resistant materials, the valves can be used in a wide variety of demanding applications. The NAMUR flange allows easy mounting directly to process valves. Due to the low power consumption, up to 4 valves can be connected to the Profibus PA I/O-Box 8642. The circuit function of the 6520 can easily be changed from H (5/2-way) to C (3/2-way) simply by changing the adapter plate, which is within scope of supply.
1）II 2G EEx ia IIC T6 PTB01 ATEX 2194X approved
2）Low power consumption
3）3/2- and 5/2-way
4）High flow rates
5）Long service life
电磁阀部分订货号如下：
136667 6520-W06,0-GM82-FS05-B0-024/DC-00 * MT29
141721 6520-W06,0-GM82-FS05-B0-024/DC-00 * GB11+KC63+MT29
141951 6520-C08,0-GM82-GM82-B0-024/DC-00 * MT29
