2/2-way valve for medium up to +140ºC

• Normally closed or open
• Body material: Brass, Stainless steel
• Double spindle seal
• Compact design

The externally controlled valve is pneumatically operated. It consists of a diaphragm actuator and a 2-way valve body. The diaphragm actuator moves a spindle with valve disc against a spring and switches the valve. The spindle is designed glandless with double seal. The actuator body is made out of epoxy resin.

Circuit function A
2/2-way valve, externally controlled, normally closed by spring operation with pilot valve

Circuit Function B
2/2-way valve, externally controlled, normally opened by spring,operation with pilot valve

Type 0256 - 二位二通电磁阀；直动式；适合中性介质

型号 0256 的直动式升降式衔铁电磁阀应用广泛。在无流量状态下，阀门会在弹簧力的作用下关闭。接通时，芯体受到吸引，由此克服弹簧力；阀门打开。此种阀门适合多种使用中性介质的情况，尤其适合闭塞、计量、罐充和通风等操作。

0262型直动式电磁阀技术参数如下：

0262型直动式电磁阀结构示意图如下：

0262型直动式电磁阀部分订货号如下：

026059 026257 026287 027400 026459 027643 026457 027545 026088 027734 026079 027926 027991 026200 028004 028046 028072 029106 028410 028071 026812 027891 026290 027988 026715 026298 028557 027773 027639 028080 027557

德国burkert宝德主营产品如下：
Burkert换挡阀、旁通阀、电磁阀、微流量阀、升降式衔铁阀、二通摇杆阀、隔膜阀、活塞阀、气动控制装置、活塞滑阀、脉冲阀、阀岛、隔膜阀块、开关柜、截止阀、角座阀、底部排放阀、球阀、蝶阀、先导阀、调节阀、开关、止回阀、比例阀、流量调节器、传感器、流量测量仪、流量计、变送器、隔膜泵。
