产品样本
型号描述
无流量时，带有伺服隔膜的先导式电磁阀会关闭。在该状态下，会在隔膜上方形成一个压力，该压力将阀门保持关闭。接通时，通过伺服隔膜将空间泄压，介质压力会将伺服隔膜顶起，阀门随之打开。模块化、可串接的阀门系统可随意组合成具有两种不同公称通径的分配器或集流器，这些组合结构具有不同的接口类型，最多可组合 12 个阀门。通过转动阀座，可以将各个阀门从集流器功能简单地转换或改装到分配器功能。在所有的阀门位置上，均可装配相应的补充模块（例如温度传感器）以替代阀门。
1）重叠的线圈系统 AC10
Type Description
The servo-assisted solenoid valve with servo diaphragm is normally closed (NC). In this condition, pressure builds up above the diaphragm - the valve holds tight. When energized, the space above the servo diaphragm is pressure relieved and lifted up by the medium - the valve opens. The modular extendable valve system can be built up in all possible combinations with up to 12 valves each as distributor or collector in two sizes with different port connection modules. The valve can be put together in collecting function or distributing function by easily twisting the valve insert. Any combination of functions in one block is possible. Additional functions such as temperature indication or flow measurement can be added by integrating a corresponding sensor directly into the valve block. In order to be as flexible as possible, a variety of port connections are available as standard. The inner thread port connections are at the bottom, pointing down while the outer thread port connections and the plug-on connection for hoses are pointing to the side. The block material is Polyamide glassfiber reinforced. The advantages are: Low weight and a certain chemical resistance.
1）Push-over solenoid system AC10
2）Modular valve 2/3/4-fold, hose connection
3）Body in brass DN1 …DN13
电磁阀6227隔膜阀部分订货号如下：
131956 6227-V-A10,0BBPA-FM04-5-230/50-05
133118 6227-V-A13,0BBPA-FM05-5-024/DC-05 * NA40
137648 6227-V-A10,0BBPA-FM04-5-024/DC-05
146586 SET3-6227-000-13,0-BB000A00-146586Q* NA39
150246 6227-S-A10,0BBPA-FM04-5-024/DC-05
153340 SYST-6227-MG01-0V-04-024/DC-153340
153691 SYST-6227-MG01-0V-02-024/DC-153691
153693 SYST-6227-MG01-3V-02-024/DC-153693
155353 SYST-6227-MG01-0S-07-024/DC-155353 * JF01
156351 SYST-6227-MG01-0V-08-024/DC-156351
157025 SYST-6227-MG01-3V-04-024/DC-157025 * JF01
157026 SYST-6227-MG01-3V-04-024/DC-157026 * JF01
158129 SYST-6227-MG01-0V-02-024/DC-158129 * ND13
158152 SYST-6227-MG01-0V-03-024/DC-158152 * ND13
159429 SYST-6227-MG01-3V-08-024/DC-159429 * JF01
164924 SYST-6227-MG01-3V-09-024/DC-164924 * PD19
164925 SYST-6227-MG01-3V-04-024/60-164925 * PD19
165427 SYST-6227-MG01-0V-02-024/DC-165427 * JF01
166673 SYST-6227-MG01-0V-09-024/DC-166673 * JF01
168522 SYST-6227-MG01-0V-03-230/50-168522 * ND13
170784 SYST-6227-MG01-3S-06-230/50-170784 * JG54
174260 SET3-6227-000-10,0-00000000-174260
176460 6227-S-A10,0AAPA-FM04-5-024/DC-05
177441 6227-V-A10,0FFPA-FM04-5-024/DC-05
191980 MICR-6227-WE-191980M-FLANSCH
192139 MICR-6227-WE-192139N-FLANSCH
197566 SYST-6227-MG01-0V-04-024/DC-197566
459215 6227-V-A10,0BBPA-FM04-5-120/60-05 * PD19
459220 6227-V-A13,0BBPA-FM05-5-024/60-05 * PD19
459222 6227-V-A10,0BBPA-FM04-5-024/DC-05 * NA40+PD19
459223 6227-V-A13,0BBPA-FM05-5-024/DC-05 * NA40+PD19
647263 SET3-6227-000-13,0-BB000A00-647263R
652382 KOMP-707-6227-G652-382-00-652382
703403 MKEN-6227-00000000-703403G
703409 MKEN-6227-00000000-703409N
703410 MKEN-6227-00000000-703410A
703411 MKEN-6227-00000000-703411X
703412 MKEN-6227-00000000-703412Y
703413 MKEN-6227-00000000-703413Z
703414 MKEN-6227-00000000-703414S
703415 MKEN-6227-00000000-703415T
703416 MKEN-6227-00000000-703416U
703417 MKEN-6227-00000000-703417V
703732 MKEN-6227-00000000-703732G
703734 MKEN-6227-00000000-703734A
703736 MKEN-6227-00000000-703736C
